Self-propelled sunflower seed harvester

The self-propelled sunflower seed harvester is a highly efficient agricultural harvesting machine that integrates the functions of picking , conveying, threshing, cleaning, and collecting . It is designed for large-scale planting of sunflower seeds . This product is suitable for sunflower crops with various planting row spacings, and is also suitable for harvesting different varieties of edible sunflowers .

Product structure characteristics

The machine is equipped with a domestically produced high-quality National IV diesel engine, which is powerful, energy-saving and environmentally friendly, with low fuel consumption and advanced performance indicators; the chassis adopts a double-beam integral bridge frame design, and is combined with a high-quality and advanced mechanical shift + continuously variable transmission drive axle box, which has reliable quality, low center of gravity, good stability and high safety factor; the conveyor belt feeding mechanism is adopted, which can keep the sunflower tray with the sunflower seeds facing upward during the transportation process, effectively reducing seed leakage; the harvesting platform adopts hydraulic control and can be adjusted according to the height of the sunflower, overcoming the problem of uneven height of edible sunflowers and difficult to harvest, and the tray will not be lost; the thresher screen bottom is height-adjustable, and the gap between the drum and the screen is adjusted according to the operating speed and the amount of thresher feed, effectively reducing the grain The scratch rate and breakage rate are reduced; the cleaning system adopts a vibrating fish scale screen and a fan to remove impurities, which effectively improves the cleanliness of the grains and makes the cleaning clean and thorough; the chain conveyor bucket seed lifting mechanism can effectively reduce the scratch rate and breakage rate of the grains; the large-volume seed storage box design can reduce the number of unloading times and improve work efficiency; the hydraulic rollover unloading is simple to operate and convenient to unload; it is equipped with a luxurious cab with air conditioning, and image display screens for reversing, seed collecting box and thresher, so that the driver can observe the surrounding environment and the conditions during the harvesting process anytime and anywhere during reversing, reduce fatigue intensity, and be safer when driving; it adopts a conveyor belt type sunflower plate direct installation mechanism (optional), which is efficient and fast in vehicle transportation and has strong adaptability to operations. This product is ingeniously conceived, simple to operate, easy to maintain, high in harvesting efficiency, good in operation effect, and has a good market promotion and application value.

Main technical parameters
