Self-propelled flax harvester (flax pulling)
Update time:2025-12-17

Product Introduction
Technical Parameters


The 4YMB-2 self-propelled flax harvester, manufactured by Dezhou Chunming Agricultural Machinery Co., Ltd., is a mechanized harvesting equipment specifically designed for flax crops. It is suitable for pulling up flax and sesame plants during their yellow ripening stage, and evenly laying the flax stalks in the field for natural degumming (i.e.,dew-watering method: its core is the decomposition of gum through natural microbial fermentation), thereby achieving effective separation of flax fiber and core xylem.

The walking mechanism of this machine adopts hydraulic stepless speed regulation and four-wheel drive.


Main Technical Parameters


Project

Unit

Main Technical Parameters

Model Name

/

4YMB-2 self-propelled flax harvester

Operating speed

km/h

8~15

Walking speed

km/h

20~30

Engine power

kW

162

Working efficiency

hm²/h

1.0~1.8

Homework width

mm

2400

Structural quality

kg

7500

External dimensions (Length × Width × Height)

mm

7700×3300×2900

Drive type

/

Four-Wheel Drive

Walking style

/

Hydraulic
